sbi export: architectures and constraints

LANfactory's transform_sbi_to_onnx wraps a trained sbi estimator and writes a single-trial ONNX file that HSSM's loglik_kind="approx_differentiable" path can consume exactly like a LAN export (the artifact rules are collected in The ONNX likelihood contract). Use it to bring sbi-trained NLE density estimators or NRE ratio classifiers into a HSSM model.

Installation

pip install lanfactory[all]

The all extra pulls sbi>=0.26 and nflows>=0.14 in addition to LANfactory's other optional integrations.

Quick start (NLE)

import torch
from sbi.inference import NLE_A
from sbi.utils import BoxUniform
from lanfactory.onnx import transform_sbi_to_onnx

# 1. Train a likelihood estimator (your simulator + prior here).
prior = BoxUniform(low=torch.tensor([-3.0, -3.0]), high=torch.tensor([3.0, 3.0]))
inference = NLE_A(prior=prior, density_estimator="maf")
theta = prior.sample((5_000,))
x = my_simulator(theta)                       # shape: (5000, x_dim)
estimator = inference.append_simulations(theta, x).train()

# 2. Export to a HSSM-compatible ONNX file.
transform_sbi_to_onnx(
    estimator,
    "ddm_nle.onnx",
    mode="nle",
    example_theta_dim=theta.shape[-1],
    example_x_dim=x.shape[-1],
)

# 3. Hand it to HSSM exactly like a LAN file.
import hssm
model = hssm.HSSM(
    data=obs_data,
    model="ddm",
    model_config=my_model_config,
    loglik_kind="approx_differentiable",
    loglik="ddm_nle.onnx",
    p_outlier=0,
)
idata = model.sample(sampler="numpyro", draws=500, tune=500, chains=2)

Quick start (NRE)

from sbi.inference import NRE_A
inference = NRE_A(prior=prior)
classifier = inference.append_simulations(theta, x).train()
transform_sbi_to_onnx(
    classifier,
    "ddm_nre.onnx",
    mode="nre",
    example_theta_dim=theta.shape[-1],
    example_x_dim=x.shape[-1],
)

The classifier logit is log p(x, θ) / p(x) p(θ) = log p(x | θ) − log p(x). The θ-independent log p(x) term drops out under MCMC and under HSSM's posterior path, so the raw logit is consumed as the log-likelihood (up to a constant). No Jacobian correction is needed — ratios are invariant to z-score standardization.

Supported architectures (v1)

Method Density / classifier Embedding nets Status
NLE_A MAF none, FC on θ ✅ supported
NLE_A MDN, MoG none, FC on θ ✅ supported (untested at v1, expected to work)
NRE_A / B / C / BNRE MLP classifier (with norm_layer=nn.Identity) none, FCEmbedding, CNNEmbedding ✅ supported

Explicitly out of scope (v1)

Excluded Reason
Neural Spline Flows (NSF coupling, NSF autoregressive) jaxonnxruntime is missing the SearchSorted op. Targeted for a future upstream PR.
FMPE (flow-matching), NPSE (score-based) log_prob requires ODE integration; not ONNX-exportable.
NPE / SNPE Posterior-shaped, not likelihood-shaped. The HSSM ecosystem's current scope is neural likelihood surrogates.
TabPFN / NPE-PFN Transformer with in-context inputs; awkward shape handling. Deferred.

The exporter rejects estimators whose class name is in the unsupported set with a clear ValueError. If you encounter an unsupported architecture, please open an issue.

Known constraints

Three constraints arose during validation and apply to anyone training their own sbi estimators for export:

  1. For NLE with density_estimator="maf", use ≥2D for both θ and x. A 1D MAF in sbi collapses to a degenerate Gaussian path that emits zero-width Gemm contractions jaxonnxruntime cannot translate. This is a training-time limitation of sbi/nflows, not something transform_sbi_to_onnx enforces, and it is MAF-specific — NRE ratio classifiers export fine in 1D, and other density estimators (MDN, MoG) may not share it (untested at v1). Use 2D or higher for MAF NLE (this is the realistic case anyway).

  2. Disable LayerNorm in NRE MLP classifiers. jaxonnxruntime does not implement the LayerNormalization op. When using classifier_nn(model="mlp", ...), pass norm_layer=nn.Identity to skip it:

from torch import nn
from sbi.neural_nets import classifier_nn

classifier_builder = classifier_nn(
    model="mlp",
    embedding_net_x=my_embedding,
    norm_layer=nn.Identity,    # <-- required for ONNX export
)
  1. Enable JAX x64 before importing JAX in the consuming process. ONNX graphs from torch.onnx.export carry int64 shape/index tensors. With JAX's default 32-bit mode, those get silently truncated to int32, producing ~0.5-unit drift in log-prob outputs. Set:
import jax
jax.config.update("jax_enable_x64", True)
# ...subsequent imports of jaxonnxruntime, hssm, etc.

HSSM's onnx2jax consumer sets the related jaxort_only_allow_initializers_as_static_args = False flag automatically, but the x64 setting is process-wide and must be opted into by the caller.

Numerical guarantees

The C2–C5 regression tests assert:

  • Forward pass: torch reference, onnxruntime, and jaxonnxruntime all agree to atol=1e-5 on fixed inputs.
  • Gradients: jax.grad of the translated graph agrees with torch.autograd.grad on the original estimator to atol=1e-4.

If you run into precision issues smaller than these thresholds, please open an issue with a minimal repro.

Float precision

ONNX exports default to float32. PyMC defaults to float64. When sampling, either:

  • Cast at the JAX boundary, or
  • Set pytensor.config.floatX = "float32" for the whole model.

HSSM handles this consistently in its approx_differentiable path; if you're hand-rolling a model with pm.CustomDist you'll need to do this yourself.
